螺牙规格: 公制牙(Metric)、PG牙、G牙、NPT牙。
产品材质: A.C.F部分采用UL认可之无卤素（Halogen-Free）尼龙PA66(防火等级UL94V-2)制成;(可定制UL认
可的V-0防火等级尼龙原料);B.D部分采用三元乙丙(EPDM)耐候橡胶制成。(可定制耐寒、耐高温橡胶;耐高酸
碱、耐化学与抗腐蚀橡胶)。
保护等级: IP68
工作温度: 静态-40℃至100℃,或瞬间可耐热至120℃;动态-20℃至80℃，或瞬间可耐热至100℃.
产品特性: 本款高性能防水尼龙浪管盒接头能完美地抗水压，是一款即使拉扯波纹管也能完全保持气密的产
品。产品广泛地应用于移动式的自动化设备之防水、防油与气密的场合。
颜色种类: 黑色B、灰色G，白色W其它颜色可定做，（防水IP68，抗强拉力，材质环保）
|
螺纹规格
|
产品型号 黑色B 灰色G 白色W
|
适配软管
|
螺纹外径
|
螺纹长度
|
适用最大孔径
|
包装数量
|
|
M12X1.5
|
TLYBFC-M12-E-10 (B、G、W)
|
1/4
|
12
|
9
|
10
|
50
|
|
M16X.15
|
TLYBFC-M16-E-13 (B、G、W)
|
5/16
|
16
|
15
|
13
|
50
|
|
M16X1.5
|
TLYBFC-M16-E-15 (B、G、W)
|
3/8
|
16
|
15
|
16
|
50
|
|
M16X1.6
|
TLYBFC-M16-E-18 (B、G、W)
|
3/8
|
16
|
15
|
18.3
|
50
|
|
M20X1.5
|
TLYBFC-M20-E-15 (B、G、W)
|
3/8
|
20
|
15
|
16
|
50
|
|
M20X1.5
|
TLYBFC-M20-E-18 (B、G、W)
|
3/8
|
20
|
15
|
18.3
|
50
|
|
M20X1.5
|
TLYBFC-M20--E-21 (B、G、W)
|
1/2
|
20
|
15
|
22
|
50
|
|
M25X1.5
|
TLYBFC-M25-E-21 (B、G、W)
|
1/2
|
25
|
15
|
22
|
50
|
|
M25X1.5
|
TLYBFC-M25-E-26 (B、G、W)
|
3/4
|
25
|
15
|
26.5
|
50
|
|
M25X1.5
|
TLYBFC-M25-E-28 (B、G、W)
|
3/4
|
25
|
15
|
28.5
|
50
|
|
M32X1.5
|
TLYBFC-M32-E-34 (B、G、W)
|
1**
|
32
|
15
|
34.5
|
10
|
|
M40X1.5
|
TLYBFC-M40-E-42 (B、G、W)
|
1 1/4
|
40
|
20
|
43
|
10
|
|
M50X1.5
|
TLYBFC-M50-E-48 (B、G、W)
|
1 1/2
|
50
|
22
|
48
|
10
|
|
M63X1.5
|
TLYBFC-M63-E-54 (B、G、W)
|
2**
|
63
|
25
|
55
|
10
|
|
M63X1.5
|
TLYBFC-M63-E-60 (B、G、W)
|
2**
|
63
|
25
|
61
|
10
|
|
PG16
|
TLYBFC-PG16-E-15 (B、G、W)
|
3/8
|
22.5
|
12
|
16
|
50
|
|
PG16
|
TLYBFC-PG16-E-18 (B、G、W)
|
3/8
|
22.5
|
12
|
18.3
|
50
|
|
G（PF）1/2
|
TLYBFC-PG21-E-15 (B、G、W)
|
3/8
|
20.955
|
12
|
16
|
50
|
|
G（PF）1/2
|
TLYBFC-PG21-E-18 (B、G、W)
|
3/8
|
20.955
|
12
|
18.3
|
50
|
|
G（PF）1/2
|
TLYBFC-PG21-E-21 (B、G、W)
|
1/2
|
20.955
|
15
|
22
|
50
|
|
G（PF）3/4
|
TLYBFC-PG26-E-26 (B、G、W)
|
3/4
|
26.441
|
15
|
26.5
|
25
|
|
G（PF）3/4
|
TLYBFC-PG26-E-28 (B、G、W)
|
3/4
|
26.441
|
15
|
28.5
|
25
|
|
G（PF）1**
|
TLYBFC-PG33-E-34 (B、G、W)
|
1**
|
33.249
|
15
|
34.5
|
10
|
|
G（PF）1 1/4
|
TLYBFC-PG42-E-42 (B、G、W)
|
1 1/4
|
41.91
|
20
|
43
|
10
|
|
产品型号
|
适配软管
|
螺纹规格
|
螺纹外径
|
螺纹长度
|
幅体最小通径
|
包装单位
|
|
TLYBFC-FS90-M16-13.0
|
AD13.0
|
M16X1.5
|
16
|
10
|
10.7
|
50
|
|
TLYBFC-FS90-M16-15.8-ST
|
AD15.8
|
M16X1.5
|
16
|
10
|
11.1
|
50
|
|
TLYBFC-FS90-M16-15.8
|
AD15.8
|
M16X1.5
|
16
|
15
|
11
|
50
|
|
TLYBFC-FS90-M20-15.8-ST
|
AD15.8
|
M20X1.5
|
20
|
10
|
14.7
|
50
|
|
TLYBFC-FS90-M20-15.8
|
AD15.8
|
M20X1.5
|
20
|
15
|
14.7
|
50
|
|
TLYBFC-FS90-M16-18.5-ST
|
AD18.5
|
M16X1.5
|
16
|
10
|
11
|
50
|
|
TLYBFC-FS90-M16-18.5
|
AD18.5
|
M16X1.5
|
16
|
15
|
11
|
50
|
|
TLYBFC-FS90-M20-18.5-ST
|
AD18.5
|
M20X1.5
|
20
|
10
|
14.7
|
50
|
|
TLYBFC-FS90-M20-18.5
|
AD18.5
|
M20X1.5
|
20
|
15
|
14.7
|
50
|
|
TLYBFC-FS90-M25-21.2-ST
|
AD21.2
|
M25X1.5
|
25
|
10
|
14.8
|
25
|
|
TLYBFC-FS90-M25-21.2
|
AD21.2
|
M25X1.5
|
25
|
15
|
14.8
|
25
|
|
TLYBFC-FS90-M25-25.5-ST
|
AD25.5
|
M25X1.5
|
25
|
10
|
19.2
|
20
|
|
TLYBFC-FS90-M25-25.5
|
AD25.5
|
M25X1.5
|
25
|
15
|
19.2
|
20
|
|
TLYBFC-FS90-M25-28.5-ST
|
AD28.5
|
M25X1.5
|
25
|
10
|
19.9
|
20
|
|
TLYBFC-FS90-M25-28.5
|
AD28.5
|
M25X1.5
|
25
|
15
|
19.9
|
20
|
|
TLYBFC-FS90-M32-34.5
|
AD34.5
|
M32X1.5
|
32
|
15
|
26.2
|
10
|
|
TLYBFC-FS90-M40-42.5
|
AD42.5
|
M40X1.5
|
40
|
20
|
34
|
10
|
|
适配软管
|
螺牙规格
|
型号
|
螺纹外径 AG(mm)
|
螺纹长度 GL(mm)
|
幅体最小通径 L.D(mm)
|
|
AD10
|
M12X1.5
|
TLYBFC-E-WM12-10
|
12
|
9
|
|
|
AD13
|
M16X1.5
|
TLYBFC-WMG16-13
|
16
|
10
|
10.7
|
|
AD15.8
|
M16X1.5
|
TLYBFC-WMG16-15.8
|
16
|
10
|
11
|
|
M20X1.5
|
TLYBFC-WMG20-15.8
|
20
|
10
|
14.7
|
|
AD18.5
|
M16X1.5
|
TLYBFC-WMG16-18.5
|
16
|
10
|
11
|
|
M20X1.5
|
TLYBFC-WMG20-18.5
|
20
|
10
|
14.7
|
|
AD21.2
|
M20X1.5
|
TLYBFC-WMG20-21.2
|
20
|
10
|
14.7
|
|
AD25
|
M25X1.5
|
TLYBFC-WMG25-25
|
25
|
10
|
19.2
|
|
AD28.5
|
M25X1.5
|
TLYBFC-WMG25-28.5
|
25
|
10
|
19.2
|
|
AD34.5
|
M32X1.5
|
TLYBFC-WMG32-34.5
|
32
|
15
|
26.2
|
|
AD42.5
|
M40X1.5
|
TLYBFC-WMG40-42.5
|
40
|
20
|
34
|
|
M50X1.5
|
TLYBFC-WMG50-42.5
|
40
|
20
|
|
|
AD48
|
M50X1.5
|
TLYBFC-WMG50-48
|
50
|
20
|
|
